CNC Beam Saw Heavy Duty Panel Saw
Self-developed | Factory Direct|Reliable Quality Automatic Feeding \Automatic Positioning High Cutting Efficiency\High Cutting Precision
Description
Control system | PC with cutting optimization software | |
Max.cutting length | 3300mm | |
Max.cutting thickness | 120mm | |
Min.cutting size | 35*35mm | |
Saw blade system | Main saw blade | Size: Φ450*75mm |
Speed: 4000r/min | ||
Scoring saw blade | Size: Φ200*50mm | |
Speed: 6000r/min | ||
Saw system | Saw carrier forward speed | 100mm |
Saw carrier backward | 120mm | |
Sawing motor power | 15kw+2.2kw | |
Saw carrier driving motor | 1.8kw | |
Auto feeding system | Pneumatic holding gripers | 10 groups |
Feeding servo motor | 1.8kw | |
Loading system | Air floating table | 3pcs |
Table height | 960mm | |
Floating fan power | 3kw | |
Working air pressure | 6-7kg/cm² | |
Net weight | 5800KG | |
Overall size | 6600*6400*1800mm | |
Relevant information
undefined
Located in the beautiful coastal city-Qingdao.Qingdao SOSN Machinery Co., Ltd is a professional manufacturer of woodworking machinery, and have been in this line for more than 30 years.
